Model No.MCD-WS-200

Voltage (V) 90-305
LED Power (W) 200
System Power (W) 220
Luminous Flux:18000lm
Beam Angle(°) 90/150
Color Temp:4000K-7000K
Typicsr CRI:80
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):350*388
Weight(Kg):8.4
IP-protectino:IP20
金口:E39
MEANWELL　電源別置型
強化ガラス

Model No.MCD-WS-80

Voltage (V) 90-305
LED Power (W) 80
System Power (W) 87
Luminous Flux:7200lm
Beam Angle(°) 90/150
Color Temp:4000K-7000K
Typicsr CRI:80
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):250*272
Weight(Kg):2.5
IP-protectino:IP20
金口:E39
MEANWELL　電源別置型
強化ガラス

Model No.MCD-ED-100

Voltage (V) 90-277
LED Power (W) 100
System Power (W) 110
Luminous Flux:13000lm
Beam Angle(°) 90/120
Color Temp:4500K-5500K
Typicsr CRI:80
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):222*H171
Weight(Kg):2.4
IP-protectino:IP65
MEANWELL　電源組込型
Luminous Efficiency 130lm/w

Model No.MCD-ED-150

Voltage (V) 90-277
LED Power (W) 150
System Power (W) 155
Luminous Flux:19500lm
Beam Angle(°) 90/120
Color Temp:4500K-5500K
Typicsr CRI:80
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):280*H174
Weight(Kg):3.3
IP-protectino:IP65
MEANWELL　電源組込型
Luminous Efficiency 130lm/w

Model No.MCD-ED-180

Voltage (V) 90-277
LED Power (W) 180
System Power (W) 185
Luminous Flux:23500lm
Beam Angle(°) 90/120
Color Temp:4500K-5500K
Typicsr CRI:80
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):280*H171
Weight(Kg):4.1
IP-protectino:IP65
MEANWELL　電源組込型
Luminous Efficiency 130lm/w

Model No.MCD-WS-18

LED Power (W) 18
System Power (W)
Luminous Flux:18W/2000lm
Beam Angle(°) 360
Color Temp:3500K-6000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):88*201mm
Weight(Kg):18W/0.5Kg
IP-protectino:IP65
金口:E39/E26
電源組込型

Model No.MCD-WS-40

LED Power (W) 40
System Power (W)
Luminous Flux:40W/5200lm
Beam Angle(°) 360
Color Temp:3500K-6000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):88*231mm
Weight(Kg): 40W/0.8Kg
IP-protectino:IP65
金口:E39/E26
電源組込型

Model No.MCD-WS-60

LED Power (W) 60
System Power (W)
Luminous Flux:60W/7500lm
Beam Angle(°) 360
Color Temp:3500K-6000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):88*287
Weight(Kg):0.78Kg
IP-protectino:IP65
金口:E39
電源組込型

Model No.MCD-WS-75

LED Power (W) 75
System Power (W)
Luminous Flux:75W/9100lm
Beam Angle(°) 360
Color Temp:3500K-6000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):88*258
Weight(Kg):0.8Kg
IP-protectino:IP65
金口:E39
MEANWELL　電源別置型

Model No.MCD-WS-90

LED Power (W) 90
System Power (W)
Luminous Flux:11000lm
Beam Angle(°) 360
Color Temp:3500K-6000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):107*247mm
Weight(Kg):1Kg
IP-protectino:IP65
金口:E39
MEANWELL　電源別置型

Model No.MCD-WS-20

LED Power (W) 20
System Power (W) 24
Luminous Flux:1600lm
Beam Angle(°) 120
Color Temp:5400K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):120*134
Weight(Kg):0.4
IP-protectino:IP65
金口:E39

Model No.MCD-WS-45

LED Power (W) 45
System Power (W) 48
Luminous Flux:4800lm
Beam Angle(°) 120
Color Temp:4000K-7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):165*233
Weight(Kg):0.95
IP-protectino:IP65
金口:E39

Model No.MCD-WS-45

LED Power (W) 45
System Power (W) 48
Luminous Flux:4800lm
Beam Angle(°) 120
Color Temp:4000K-7000K
Typicsr CRI:82
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):165*233
Weight(Kg):0.95
IP-protectino:IP65
金口:E39

Model No.MCD-ID-60

Voltage (V) 90-277
LED Power (W) 60
System Power (W) 65
Luminous Flux:7800lm
Beam Angle(°) 90/120
Color Temp:4500K-5500K
Typicsr CRI:80
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):220*H195
Weight(Kg):1.2
IP-protectino:IP65
MEANWELL　電源別置型
金口:E39
Luminous Efficiency 130lm/w

Model No.MCD-ID-100

Voltage (V) 90-277
LED Power (W) 100
System Power (W) 105
Luminous Flux:13000lm
Beam Angle(°) 90/120
Color Temp:4500K-5500K
Typicsr CRI:80
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):220*H195
Weight(Kg):1.2
IP-protectino:IP65
MEANWELL　電源別置型
金口:E39
Luminous Efficiency 130lm/w

Model No.MCD-ID-180

Voltage (V) 90-277
LED Power (W) 180
System Power (W) 185
Luminous Flux:23500lm
Beam Angle(°) 90/120
Color Temp:4500K-5500K
Typicsr CRI:80
Lanp Life(hrs):50000
Operating Tenp(℃):-40to+45
Dimension(mm):220*H261.5
Weight(Kg):1.2
IP-protectino:IP65
MEANWELL　電源別置型
金口:E39
Luminous Efficiency 130lm/w
